CA-1011: Heavy-Duty Draw Latch

CA-1011 Heavy-Duty Draw Latch – Adjustable Tension, Long Blade Design, High Clamping Force

Engineered for demanding environments, the CA-1011 Draw Latch combines a rugged long-blade design with adjustable tension capabilities—offering reliable fastening, secure closure, and quick-release functionality where it counts.

🔩 Key Features:

• High Clamping Force:

  • 75–160 lbs for steel configurations

  • 60–120 lbs for stainless steel installations

• Ultimate Load Rating:

  • 400 lbs (Steel)

  • 380 lbs (Stainless)

• Adjustable Tension:
  Fine-tune clamping pressure by adjusting the mounting hole distance—ideal for compensating gasket compression or material shifts over time.

• Extended Reach:
  Long-blade design ensures reliable closure even in hard-to-access or offset applications.

• Durability:

  • Built for high-vibration environments

  • Maintains performance across indoor and outdoor conditions

  • Consistent operation despite temperature and environmental fluctuations

🧰 Specifications:

• Weight: 46g per unit

• Strike Compatibility: Fits SK-4000 strike plates

• Packaging: Supplied in bulk – 300 units per box

✅ Ideal Applications:

• Transportation equipment

• Heavy-duty enclosures and cabinets

• Industrial machinery

• Panel systems requiring secure, adjustable clamping and fast access

Whether you're securing access panels or fine-tuning tension in custom builds, the CA-1011 delivers strength, flexibility, and reliability in one rugged latch.
